| Place of Origin: | China |
|---|---|
| Brand Name: | Sanlo |
| Certification: | ISO9000 |
| Model Number: | customize |
| Minimum Order Quantity: | 500 |
| Price: | negotiable |
| Packaging Details: | Box |
| Delivery Time: | 30days |
| Payment Terms: | T/T, Western Union |
| Special: | Customize | Delivery Time: | 20-30days |
|---|---|---|---|
| Main Material: | 316L | Use Place: | Switch |
| Principle: | Switching Principle | Main Country: | European And American |
| High Light: | sump pump float ball,cistern ball float |
||
customize switch float ball with the handle 80*50 from Sanlo company with the top quality
Video: https://youtu.be/IZC9AvFdK1M
Description:
This product is the cover of the valve. It is our old customer who wants us to help. The customer provides the drawings and technical parameters. We will help you to verify and modify it later. After confirming with the customer, we will produce a sample and send it to the customer for confirmation. After the final confirmation, the customer will start the final production. Before leaving the factory, we will check the appearance of the product to ensure that it is delivered to the customer.
Working principle:
The float level gauge is a magnetic float ball as a measuring component. Through the magnetic coupling action, the resistance inside the sensor changes linearly. The change of the resistance is converted into a 4~20mA standard current signal by the smart converter, and the percentage of the liquid level can be displayed on the spot. 4~20mA current and liquid level value, remote transmission supply control room can realize automatic detection, control and recording of liquid level. The meter is suitable for the sewage treatment of petroleum, chemical, electric power, light industry and medicine industries and the measurement of medium liquid level in various atmospheric and pressure vessels, especially for the liquid level measurement of underground storage tanks and storage tanks.
Technology:
| Shape | Dimensions ΦA×B×ΦC | Material | Thickness(mm) | Pressure(Mpa) | Morphology | Connection Type |
| Φ70×36×Φ16 | 304 316L | 0.8 | 2.5 | Character/Polishing | ||
| Φ80×41×Φ16 | 0.8 | 2.5 | Character/Polishing | |||
| Φ110×42×Φ16 | 0.8 | 2.5 | Character/Polishing | |||
| Φ146×56×Φ18 | 0.8 | 1.6 | Character/Polishing | |||
| Φ170×68×Φ18 | 0.8 | 1.6 | Character/Polishing | |||
| Φ225×80×Φ25 | 1.0 | 1.6 | Character/Polishing | |||
| Φ278×128×Φ30 | 1.2 | 1.6 | Character/Polishing | |||
| Φ325×105×Φ30 | 1.2 | 1.6 | Character/Polishing | |||
| Φ375×141×Φ30 | 1.5 | 1.6 | Character/Polishing | |||
| Φ150×70×Φ16 | 316L | 1.0 | 3.2 | Character/Polishing | ||
| Φ190×105×Φ16 | 1.2 | 2.5 | Character/Polishing | |||
| Φ240×125×Φ22 | 1.5 | 2.2 | Character/Polishing |
Application:
Float switch
Level controller
Level gauge magnetic flap
traps
exhaust valve
float valve
level gauge
pneumaatic diaphragm pump
Our biggest advantage:
In addition to our nationally leading cesium mass spectrometry testing equipment, we can ensure that 100% of the quality products are not leaked. What's more, we have our own second inspection. The factory ensures the technology of the products, but we also guarantee that Before delivery, there is a special person to check the appearance of the product. If there is a trace of it, we will immediately return to the factory to provide a product that is aesthetically pleasing, so as to ensure that the products that arrive at the customer are all boutique products. And after the test, we will give a second test report to the customer to ensure our high product quality.
Testing :
Float water leak rate is one of important indicators for assessing the quality of the product. With increasing requirements of our customers for product quality, conventional detection methods cannot meet such requirements any more. In order to ensure that we always take the lead in the industry in terms of product quality, SanLo is the first one which has adopted anti-leak equipment for the purpose of military missile detection to ensure that all metal float products fully achieve zero-leak.
The helium mass spectrometry leak detector is a kind of vacuum detection equipment mainly for airtightness detection and also a leak detection instrument that uses helium as leak indication gas. By using safe helium for non-invasive leak detection and with such characteristics of high detection accuracy and clear leak location, the helium mass spectrometry leak detector is gradually replacing conventional leak detection methods and won’t miss any minor leak. Therefore, it can improve our work efficiency and the yield, thus offering the most efficient guarantee to our customers in using our products.
